Technical specifications
- Technical details (Metric)
| Fuel | Petrol |
| Brand | B&S Vanguard |
| Power (kW) | 13.2 kW |
| Weight incl. oil | 119 kg |
| Dimensions (LxWxH) | 790x605x745 mm |
| Oil flow | 20 l/min – 40 l/min |
| Maximum pressure | 145 bar |
| Fuel capacity | 8.5 l |
| Hose included | no |
| Power On Demand (POD) | no |
| Oil control: engine oil | yes |
| Electric start | yes |
| Filtration | 25μ filter in return line. Filter by-pass valve in valve block. |
| Cooling system | Thermostatically controlled air blast oil cooler. |
| EHTMA class | C/D/E |
| Part number | 1807 0160 38 |
| Part number (not sold within EU) | 1807 0160 40 |
| Sound power level guaranteed (2000/14/EC) | 101 dB(A) |
| Sound pressure level (ISO 11203) | 89 Lp. dB(A) |
- Technical details (US/Imperial)
| Fuel | Petrol |
| Brand | B&S Vanguard |
| Power (kW) | |
| Weight incl. oil | |
| Dimensions (LxWxH) | 790x605x745 mm |
| Oil flow | |
| Maximum pressure | |
| Fuel capacity | |
| Hose included | no |
| Power On Demand (POD) | no |
| Oil control: engine oil | yes |
| Electric start | yes |
| Filtration | 25μ filter in return line. Filter by-pass valve in valve block. |
| Cooling system | Thermostatically controlled air blast oil cooler. |
| EHTMA class | C/D/E |
| Part number | 1807 0160 38 |
| Part number (not sold within EU) | 1807 0160 40 |
| Sound power level guaranteed (2000/14/EC) | 101 dB(A) |
| Sound pressure level (ISO 11203) | 89 Lp. dB(A) |
Easy oil check
To facilitate control and refills of hydraulic oil, the sight glass and filler cap are placed together.
Uptime is cool
Built-in hydraulic oil cooler extends component lifetime and increases reliability in tough, hot conditions.
Serve and protect
A robust frame and strong panels protect all vital parts. All service points are easily accessible.
